Modal-S2V Ultimate 3D Alignment Machine Make in India

Modal-S2V Ultimate 3D Alignment Machine Make in India +
Modal-S2V Ultimate 3D Alignment Machine Make in India +
Modal-S2V Ultimate 3D Alignment Machine Make in India +

Modal-S2V Ultimate 3D Alignment Machine Make in India

Technical Specifications

  • Wheel Size:12" 24"

  • Tyre Diameter:Unlimited

  • Track Width:48" 96"

  • Wheelbase:79" 180"

  • Power Requirement:120 / 230V, Single Phase, 50Hz

Features

  • Best suited for mass production line

  • Machine can be easily installed within a compact space

  • Customized distance between camera poles; adjustable from 5.6" to 11"

Send Enquiry Call Now

Product Description

Measurement Item Display Accuracy Camber Caster Kingpin Inclination Toe-in & Toe-out Set Back Thrust Angle Wheel Deviation Axis Deviation
Accuracy 0.01° / 0.1mm ±2° ±6° ±6° ±2° ±2° ±2° ±2mm ±2mm
Measurement Range — ±10° ±20° ±23° ±20° ±5° ±5° — —
×
